6. Timer
Selection between continuous operation and switching operation
• Slide switch for selecting the operating mode (Fig. 4):
Position
Setting the time
• Turn the setting ring with the printed times clockwise until the arrow points to the current time (Fig. 4).
• The timer only runs when the product is supplied with power.
Setting the switch-on/switch-off times
• You can use the segments to set the switch-on and switch-off times in 15-minute intervals.
• A segment pushed outwards activates the socket, a segment pushed inwards switches the sockets off (Fig. 4).
7. Cleaning
• Clean the product with a dry, dust-free cloth. Do not use solvents or abrasive cleaners for cleaning.
8. Technical data
Rated voltage: 230 V~
Rated current: 16 A
Max. Connected load: 3680 W
Temperature range: -15 °C to +40 °C
IP protection class: IP44 (splash-proof) (only if connection cables and/or mains plug with IP44 protection class are used)
9. Disposal instructions
The symbol of a crossed-out dustbin regularly displayed on electrical and electronic equipment indicates that the respective waste equipment that has
become waste is to be collected separately from unsorted municipal waste at the end of its life. Old appliances do not belong in the household waste.
To return your used electrical appliance, please use the appropriate return and collection systems or contact the dealer from whom you purchased the
product or your local authority. As a rule, owners of WEEE must separate used batteries and accumulators that are not enclosed in the WEEE, as well as
lamps that can be removed from the WEEE without destroying it, from the WEEE before handing it in at a collection point.
4008153442537_44253_BDA_0125.indd 7
4008153442537_44253_BDA_0125.indd 7
Description
Socket is permanently switched on.
Socket is switched on and off via the timer depending on the existing settings.
The timer only switches the socket outlet with earthing contact below it
Sockets switch on from
7 to 9 a.m.
Current time:
6 a.m.
Position:
(switching mode)
7
10.02.25 08:21
10.02.25 08:21
