5. Remove the other carbon filter from the
slot in the same way.
6. Place the 2 new activated carbon filters
in their magnetized sockets by tilting
them in through the ventilation opening.
Make sure they are fully seated in their
magnetic slots.
7. Insert the liquid protection plastic into
its socket in the same way as when it
was removed.
8. Insert the oil filter.
Waste water tank
In case of intense liquid going to the ventil-
ation compartment of the product, these li-
quids are collected in the waste water tank
located under the hob. In this case, the
waste water tank should be removed, the li-
quid should be poured out and the tank
should be cleaned and reinstalled.
It is recommended to clean the
waste water tank once a month.
To remove the waste water tank:
1. Remove the top drawer located under
the hob. You should be able to reach un-
der the hob.
2. Reach the waste water tank under the
hob.
3. Unlock and remove the waste water
tank by turning the lock knob.
4. Pour out the liquid in the chamber and
clean the chamber.
5. Turn the lock knob and lock it by insert-
ing the tank back into its slot.
Cleaning the bottom cover
If the bottom cover on the bottom of the
product becomes dirty, you may be able to
remove it and clean it.
To remove the bottom cover:
1. Remove the top drawer located under
the hob. You should be able to reach un-
der the hob.
2. Reach the bottom cover from under the
hob.
3. There are 5 locks in the directions
shown by the arrow symbols on the bot-
tom cover. By releasing these locks, re-
move the bottom cover by holding it
downwards.
4. After cleaning the bottom cover, push it
upwards hard in the same direction so
that the locks fit into their slots.
EN / 30
