S P E C I F I C AT I O N S
Features:
•
19" Rack-mount DMX Controller
•
DMX 512 & RDM protocol.
•
512 DMX channels.
•
Control up to 32 intelligent fixtures, up to 18 channels each
•
32 chases, each up to 100 steps, can run 5 chases simultaneously
•
32 programmable scenes
•
Soft-patchable faders & control wheels
•
16 built-in effects generator. 9 for moving light and 7 for RGB LED fixtures
•
USB for data backup and firmware update.
Control:
•
DMX512 and RDM
•
RDM to set the DMX addresses and DMX channel mode of the fixtures from controller
•
16 channel control faders
•
Dedicated Pan/Tilt wheels (User Assignable)
•
16 Effects / Fixture select buttons
•
Sound sensitivity digitally adjustable (0%-100%), built-in Mic.
•
With Wired Digital Communication Network
Connections:
•
5pin XLR DMX Output
•
Power Supply Input
•
USB A Port
Operational Conditions:
•
Use in dry location only
•
Min. ambient temperature: 32°F (0°C)
•
Max ambient temperature: 113°F (45°C)
•
Humidity: <75%
•
Allow 6" minimum between this controller and surrounding devices or wall
Storage Conditions:
•
Store in a dry location
•
Ambient storage temperature: 77°F (25°C)
Power:
•
Power Supply: DC9V`12V 300mA min. (DC9V 1A PSU Included)
•
Power Consumption: DC9V 165mA 1.5W, DC12V 16mA 2W
Dimensions & Weight:
•
Length: 5.28" (134mm.)
•
Width: 19" (482mm.)
•
Height: 2.71" (68.9 mm.)
•
Weight: 4.7lbs.(2.13kg.)
Certifications & Rating:
•
CE, cETLus (Pending), IP20
IP20
Specifications are subject to change without notice.
