A. CAMERA
The camera works on main power with the 5V power adapter supplied.
Connect the adapter's output jack to the micro USB port (6) of the
receiver, making sure it is properly positioned.
Plug the adapter into the wall socket, the LED (7) will be green.
B. RECEIVER
1. Operation with rechargeable battery.
The 3.7 V 850 mAh Li battery is already installed in the receiver.
Connect the USB cable (c) to an adaptor (not supplied) and plug the cable into the Jack port (18) on the receiver. The power
light indicator (11) is green if the receiver battery is sufficiently charged.
N.B.: before first use of receiver, charge the lithium battery by using USB cable plugged to a socket (not included) for at
least 5 hours.
2. Battery status
When on and charged, the power light indicator (11) is green. The icon
battery's charge level.
When the battery is low, the power light indicator (11) and the battery level icon are red.
If the battery level is very low, the power light indicator (11) and the battery level icon flashed
red and a sound signal goes off. Your babyphone will soon switch itself off. Remember to
charge your babyphone's battery.
3. Recharging the battery
You can recharge the battery when the receiver is switched on. Connect the adaptor to the Jack port (18), plug the receiver
into a wall socket. The power light indicator (11) will flash green
You can also recharge your receiver when it is off. The power light indicator (11) will turn to orange and the battery level icon
will be displayed on the LCD screen (10) for 30 seconds and will indicate that the battery is recharging.
N.B.: remember to disconnect the micro USB cable and the wall socket once the battery is fully recharged. To extend battery
life and for better autonomy, wait for it to run flat before recharging.
WARNING: MAKE SURE THAT THE BATTERY IS CORRECTLY INSERTED INTO THE RECEIVER BEFORE
CONNECTING THE POWER ADAPTER TO THE MICRO USB PORT TO AVOID ANY EXPLOSIONS.
ONLY USE THE ORIGINAL BATTERY OR ONE SUPPLIED BY THE DEALER.
KEEP THE BATTERY OUT OF REACH OF CHILDREN.
1. Place the camera on a flat surface between 1m and 2.50 m from the baby's head. Point the camera lens(1) and the
microphone (5) towards the baby.
2. You can fix the camera to the wall using a wall-mounting kit and tilt it from the top down and on the sides to improve visibility.
3. Switch the receiver on by pressing the start button(12) until the power light indicator (11) is green. The image captured
by the camera lens must appear on the screen with the sound transmitted by the microphone. If the screen displays the
"disconnected" image
or the connection between 2 appliances has been broken (see CONNECTION OF THE CAMERA TO THE RECEIVER).
4. Once on, your babyphone has a sound and visual alarm (the LEDs (14) come on) to warn you when baby makes a noise.
5. The sensitivity of the microphone and the volume of the speaker can be remote controlled from the receiver menu. This
corresponds to the VOX mode (see USE OF RECEIVER CONTROL PAD).
POWER SUPPLY
STARTING THE APPLIANCE
and transmits a sound signal, it means that the appliances have not been correctly connected
ESSENTIAL BABYPHONE • Instructions for use
indicates the
EN
VOX
13
