SHORT USER MANUAL COMMAND UNIT

Contents

1. General information

1.1 Safety precautions

3. Control elements

SHORT USER MANUAL COMMAND UNIT

1. GENERAL INFORMATION

1.1 Safety precautions

Read the operating manual and installation instructions carefully before installing the system. Correct and safe operation of the

system can only be ensured if both the installation instructions and the operating instructions are observed.

2. MONTAGE

2.1 Power supply

a) The system must be connected to the 12/24-V onboard electric system.

Be sure to connect the black cable of the 3-line power supply harness to terminal 15 (switched ignition supply) of the

vehicle. Alternatively, you can also connect the black cable to line D+ (generator positive terminal, only live when

engine is running) instead of terminal 15, your vehicle's electric system permitting. In both cases, be sure to make a

function check! In both cases, both you must double-check that the safety circuit functions reliably! Keep in mind that

in some vehicles it is not permissible to connect additional power consumers to the D+ line! Note that in some vehicles,

the voltage on the D+ line may be switched off temporarily by the vehicle's electric system while driving. This would

prevent the safety circuit from functioning properly! When deciding for this type of connection, make sure that the

voltage on the D+ line is present at all times and stable while the engine is running. When in doubt, connect the safety

circuit to a line supplied via terminal 15 (via the ignition lock).
