Left Panel; Right Panel - Humanscale M/Connect 3 Pro Dock Instructions De Montage

Identifying Ports
④ ⑤ ⑥

Left Panel

Component
①
Power Button
②
USB-C Charging Port
③
USB-A Charging Port
④
DC Power In
⑤
Ethernet
⑥
USB-C Upstream Port
⑦
Bridge Port
⑧
USB-C Port
⑨
USB-A Port (2)
⑩
DisplayPort Output (2)
①
⑦
Description
Powers unit on and off
Max 30W PD/QC Compatible (Limited to 15W when USB-A ③ is in use)
5V/2.4A, BC 1.2 Compatible
20 V DC, 9A
Gigabit Ethernet, 10Mbit/100Mbit/1Gbit
Connects full featured USB-C cable to laptop, Supports PD charging at 100W max.
Important: only use USB-C cable provided with unit, other cables may void
product warranty
Connects to Hub using Bridge Cable
USB 3.2 (5V, 1.5A)
USB 3.2
Platform DP Version
Single Display
Dual Display
② ③
⑧

Right Panel

DP 1.2
3840x2160 p30
2560x1440 p60
⑨ ⑩
DP 1.4
3840x2160 p60
3840x2160 p60
