Recommended System Requirements
M/Connect 3 is a USB-C DisplayPort Alt-Mode video docking station. Unlike the M/Connect 2 which utilizes DisplayLink technology,
using a USB-C to USB-A adapter is not supported.
Multi-Stream Transport (MST) technology combines two or more video signals into a single stream through a USB-C port, which
allows the video docking station to separately display the video signals on multiple monitors.
PC Hardware:
Platform with USB-C that supports DisplayPort Alternate Mode (DP Alt Mode).
For supporting extended desktop on dual monitors, the graphic processor in the platform shall support MST.
Electrical Specifications
Environmental
Dimension
Weight
AC Power Adapter
FCC Notice
M/Connect3 Models MC3-D1 for the dock and MC3-HD for the hub.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The FCC requires the user be cautioned that any changes or modifications made to this device that are not expressly approved
by Humanscale may void the user's authority to operate the equipment.
Connections to this device must be made with shielded cables in order to maintain compliance with the Class B limits in the
FCC Rules and Regulations.
Humanscale Corporation
1114 Avenue of the Americas
New York, NY 10036
+1 (800) 400-0625
Innovation, Science and Economic Development Canada ICES-003
Compliance Notice:
CAN ICES-3 (B)/NMB-3(B)
14
Temperature - Operating
Temperature - non-Operating
Relative Humidity - Operating
Relative Humidity - non-Operating
Designed to meet RoHS and WEEE directives
Hub
Dock
2.1 kg (dock and hub)
Input Voltage
Output Voltage
Efficiency
0°C to 40°C
-20°C to 60°C
10% to 80% (non-condensing 5°C to 35°C)
5% to 90% (non-condensing -20°C to 60°C)
150mm (w) x 150mm (d) x 22.5mm (h)
191mm (w) x 90mm (d) x 23mm (h)
100 – 240VAC (50-60Hz)
20VDC, 9A
Meets US DoE VI
