SECTION 2 - HANGING THE CABINET
1. Lift the cabinet and place the cabinet onto the Mounting Bar.
2. Pull bottom of cabinet away from the wall by about 1/2" and attach four Lower Mount Clips (210-1653) onto the cabinet as shown
(some components have been hidden for clarity).
1
2
Lower Mount Clip
Wall
3. You can pre-drill 3/32" holes for the mounting clips at the predetermined location. If there is no support in the wall, use the supplied
plastic anchors with a 5/16" pre-drill hole. Secure with four 10 x 2" screws (SS674).
3
SS674
Lower Mount Clip
Wall
Part no. 209-1319-rA rev. 08/21/19
Uplift Tech Cabinet
© 2019 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376
www.robern.com
7
Installation instructions
