INSTALLATION MANUAL
WARNING:
Safety is guaranteed if these instructions are
followed and therefore they must be kept.
Installation may require the involvement of qualified
personnel. Before proceeding with installation of the
device ensure that the environmental conditions are
in compliance with and suitable for the product
characteristics. Before any operation on the device
disconnect mains power.

CONFIGURATION:

Instructions for installation and use contained in this
manual are valid for several configurations of the
LINEO device, for which there are differences.
LINEO TDM (touch sensor) model refers to the
configuration of the device that includes a dimmable
electronic switch.
LINEO model refers to the configuration of the
device that does not incorporate any switch or
sensor.
INSTALLATION:
- Fasten the bracket (A), using the screws in the pack
(B), on the installation surface in the position
wanted. To install the fixture correctly, fasten the
bracket (A) so it is against the wall and at right angles
to it (fig. 1-2).
EN
- Connect the spotlights to the adaptor and using the
extensions provided in the pack (D) following the
wiring diagram:
- SLAVE: (fig.3) (without switch)
- TDM: (fig.4) (TOUCH SENSOR master)
- Connect the feeder plug (E) to an AC outlet 230V
50/60Hz.
- Connect the device power cable to an appropriate
(check plate data printed on the product label) safe
power supply with stabilized voltage (not included)
with power 10% higher than the total load.
- If more than one device must be connected to the
power supply ensure that the total sum of the power
absorbed by the devices (check the plate data shown
on the product label) does not exceed the maximum
power permitted by the Converter.
OPERATION LINEO TDM:
LINEO TDM has a built-in electronic touch switch
that can switch the device on and off, and adjust its
brightness.
To switch the device on and off, simply touch the TD
sensor briefly.
Touch it for longer to increase or decrease the
luminosity.
The whole device flashes briefly to indicate that it
has reached the maximum brightness.
The luminosity level obtained will be saved until the
next adjustment.
