H-1131
ROLL PAPER TOWEL
DISPENSER
TOOLS NEEDED
Drill
1. Remove snap-in key from the hardware packet.
2. Align snap-in key with lock on the bottom of the
dispenser and push in until it snaps into place.
(See Figure 1).
Figure 1
1. Open cover to expose inside of decorator strip
window.
2. Slide decorator strip into place, making sure the
decorator strip is held by the plastic guides.
(See Figure 3)
3. Close cover firmly and lock.
PAGE 1 OF 9
1-800-295-5510
uline.com
Drill Bit Phillips Screwdriver
Dispenser x 1 Metal Key x 1
OPTIONAL SNAP-IN KEY INSTRUCTIONS
DECORATOR STRIP INSTALLATION INSTRUCTIONS
PARTS
Plastic Snap-In
Key x 1
3. Rotate snap-in key clockwise to open the dispenser.
(See Figure 2)
Figure 2
Figure 3
Decorator Strip
Para Español, vea páginas 4-6.
Pour le français, consulter les pages 7-9.
Wall Anchor x 5 Screw x 5
Decorator Strip Window
0218 IH-1131
