8820003 Black-2 Variable Shade Auto-Darkening Welding Helmet
BLACK-2 VARIABLE SHADE AUTO-
DARKENING WELDING HELMET
SPECIFICATIONS
Optical Classification
Viewing Area
Light State Shade
Variable Shade Control
Reaction Time
Delay Control (Dark to Light)
Sensitivity
UV/IR Protection
Arc Sensors
Power Supply
Power ON/OFF
Grind Mode
Operating Temperature
Storage Temperature
ADF Controls
Material
Headgear
Compliance
INTRODUCTION
The Black-2 Variable Shade Auto-Darkening Welding Helmet
incorporates special optical technology, helping the welder to see
the full colour spectrum with clarity while in the light state.
External controls enable the welder to adjust the DIN shade
number, plus the delay and sensitivity timing without removing
the helmet.
2
1/1/1/1
3.94 X 2.56 in. (100 x 65 mm)
DIN 3
DIN 4 to 8 / DIN 9 to 13
0.04 milliseconds (1/25,000 seconds)
0.3 to 0.9 Seconds (Adjustable)
Infinitely Adjustable
Up to Shade DIN 16 at All Times
4
Solar Panel with CR2450 Lithium
Replaceable Battery
Fully Automatic
Yes
23° ~ 131°F (-5° to 55°C)
-4° -158°F (-20° to 70°C)
External
Polyamide
Pivot
ANSI/ISEA Z87.1-2015 and CSA Z94.3-07
For technical questions call 1-800-665-8685
