Broan-NuTone HARKPM21 Instructions D'installation

HARKPM21, HARKBN24, HARKBN30 AND HARKBN36 NON-DUCT KITS
FOR USE WITH BBN1243SS, BBN1303SS, BBN2243SS, BBN2303SS,
BBN3306SS, BBN3306SSC, HBN1246SS, HBN1306SS, HBN1366SS,
PM300SS, PM400SS, PM400SSV aNd PM600SSV POWERPACK INSERTS
1. Install the powerpack insert as per installation instructions packed with the unit.
2. Remove the grease filter(s) and attach the CHARCOAL FILTER(S) (included) to the backside of
the grease filter(s) using 4 supplied metal clips per filter.
3. Reinstall the filter(s).
4. For units equipped with 6-in. round adapter damper, remove the damper flaps, then connect the
included 6-IN. TO 7-IN. ROUND TRANSITION to the 6-in. round adapter.
5. Cut hole in bottom of SOFFIT to allow clearance for the 90° ANGLE BOOT (included).
6. Locate top of 4¼" x 10¼" OPENING on soffit - centered on POWERPACK INSERT CENTERLINE.
7. Layout 4¼" x 10¼" pattern and cut opening in soffit.
8. Connect 90° ANGLE BOOT to 7-IN. ROUND DUCT (included).
9a.PM300SS, BBN1243SS
7-in. round duct end to the exhaust of the unit.
9b. a : Insert boot end into soffit and connect the 7-in. round duct end to the transition
ll other uNitS
previously installed in step 4.
10. Install GRILLE (included - not shown) into soffit opening.
11. Use metal foil tape to make all connections secure and air tight.
PM300SS,
BBN1243SS, BBN1303SS
SOFFIT
CABINET
CHARCOAL FILTER
(included) (S99010464)
HH0316
POWERPACK INSERT
CENTER LINE
INSTALLATION INSTRUCTIONS
NOTE: S
EE laST pagE fOr ThE cONTENT Of ThE NON
BBN1303SS
aNd
6-IN. TO 7-IN.
ROUND TRANSITION
(included)
OPTIONAL METAL LINER
(LB30SS or LB36SS)
C L
(purchase separately)
: Insert boot end into soffit and connect the
uNitS oNly
4¼" x 10¼"
SOFFIT OPENING
90° ANGLE BOOT
(included)
7-IN. ROUND DUCT
(included)
- .
ducT kiTS
PM400SS, PM400SSV, PM600SSV,
BBN2243SS, BBN2303SS,
BBN3306SS, BBN3306SSC,
HBN1246SS, HBN1306SS,
HBN1366SS
CHARCOAL FILTERS
(included) (S99010464-124)
C L
(S99010464-130)
(S99010464-136)
POWERPACK INSERT
CENTER LINE
SOFFIT
CABINET
