English
Specifications
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
A = 300 hours
B = 125 hours
C = 50 hours
Engine
STIHL single cylinder two-stroke engine
Displacement: 70.7 cm
Bore: 50 mm
Stroke: 36 mm
Engine power to 4.1 kW (5.6 HP)
ISO 7293: at 9500 rpm
Idle speed: 2800 rpm
Maximum permissi-
ble speed with bar
and chain: 13500 rpm
Ignition system
Electronic magneto ignition
(breakerless)
Spark plug Bosch WSR 6 F,
(suppressed): NGK BPMR 7 A
Electrode gap: 0.5 mm
42
This ignition system fulfills all
requirements of the Canadian
Interference-Causing Equipment
Regulations ICES-002.
Fuel system
All position diaphragm carburetor with
integral fuel pump
Fuel tank capacity:
Chain lubrication
Fully automatic, speed-controlled oil
pump with reciprocating piston –
additional manual oil flow control
Oil tank capacity:
Weight
3
dry, without bar and chain
MS 441:
MS 441 with handle heating:
MS 441 with wrap around han-
dlebar and handle
heating:
Cutting attachment
STIHL cutting attachments complying
with CSA Standard Z 62.3:
Rollomatic guide bars
Bar lengths:
Pitch:
Groove width:
Sprocket nose:
0.725 l
0.36 l
6.6 kg
6.7 kg
7.1 kg
40, 45, 50, 63 cm
3/8" (9.32 mm)
1.3 or 1.6 mm
11-tooth
Saw chains 3/8"
Rapid Micro Comfort (36 RMC)
Rapid Super Comfort (36 RSC)
Rapid Super Comfort 3 (36 RSC3)
Pitch: 3/8" (9.32 mm)
Drive link gauge: 1.3 or 1.6 mm
Chain sprocket
7-tooth for 3/8" (rim sprocket)
Additional cutting attachments
Additional cutting attachments
complying with CSA Standard Z 62.3
are available: see section CSA Standard
Z 62.3, "Information Sheet" in saw chain
packaging or ask a STIHL servicing
dealer.
Your STIHL servicing dealer will be
happy to help you properly match your
engine with the appropriate bar/chain
combinations to reduce the risk of
kickback injury.
