Uline H-161 Mode D'emploi

IMPULSE POLY BAG
SEALERS
NOTE: Uline model #s H-161, H-293, H-963 and
H-1252 have cutting blade.
NOTE: Cutter may have a clear, wax coating
that needs to be removed before first use. Use
caution when removing.
NOTE: Uline model #s H-458, H-163, H-190, H-306
and H-1029 do not have cutting blade.
NOTE: Once plugged in, sealer is live. Heat is
only conducted once arm is closed.
CAUTION! To provide continued protection
against risk of electric shock, connect to
properly grounded outlets only.
WARNING! Potential risk of fire or injury. Risk of
electric shock if unit is overturned, overfilled or
if power is not disconnected to clean the unit
or to replace its heating element. Disconnect
the plug from the power source while cleaning
the item or changing its heating element. Keep
children away from this product.
1. Plug the power cord into the outlet and set the timer
knob to the recommended setting based on mil
thickness. (See Recommended Settings Table on
page 3)
2. Put poly bag on the sealing platform and push down
the sealing arm. The sealer will automatically control
the seal time.
PAGE 1 OF 18
BEFORE USE
OPERATING INSTRUCTIONS
3. Once seal is complete, slide the cutter to trim the
4. Release the sealing arm.
Pour le français, consulter les pages 13-18.
NOTE: Check for calibration:
• Vibrations during shipping may have caused
sealer to fall out of calibration. Must check
heating element and microswitch integrity
before using.
• Heating element must be securely attached
at both ends. Check to ensure looped
around tension rod located near center
hinge.
• If microswitch is properly engaged, user will
hear a "click" after pressing arm down. If no
"click", see troubleshooting guide for more
details.
NOTE: The higher the number on the dial,
the longer the heat sealing time. Sealing is
complete when the light turns off.
bag (only on H-161, H-293, H-963 and H-1252).
Para Español, vea páginas 7-12.
1022 IH-161
