Operating instructions and warnings
only for qualified personnel
WARNING To ensure an appropriate level of electrical safety always keep the 230V power supply
cables apart (minimum 4 mm in the air or 1 mm through insulation) from low voltage cables (motors
power supply, controls and aerial circuits power supply) and fasten the latter with appropriate clamps
near the terminal boards.
WARNING The device shouldn't be used by children and/or persons with reduced capacities (physi-
cal, sensorial, mental). Prevent children from playing with the device. All these operations must be per-
formed only after disconnecting the power supply and operating in strict compliance with the electrical
standards and regulations in force in the nation of installation.
WARNING Using spare parts not indicated by DEA System and/or incorrect re-assembly may en-
danger people, animals and property, and may also cause malfunctioning of the products: always use
parts provided by DEA System and follow assembly instructions.

3 MODELS AND CONTENTS OF THE PACKAGE

Feeders with timed contact SSE12 are supplied inside an IP54 rated box for external assembly.

4 PRODUCT DESCRIPTION

The SSE12 device is designed for all applications where electrical equipment has to be fed or piloted
through a timed contact. The temporization foresees a programming delay of ignition or turning off of
the relay with regard to its command. Some examples of typical applications are: piloting of electro-ma-
gnets for automated closings, garden lighting, anti-theft activation/deactivation, management of simple
semaphore installations etc...
The feeder has a 12V
can be connected to some external feeders. 3 different working programs are foreseen (monostable,
bistable and bistable with separated ON/OFF). Activation commands can be given by radio, by keys or
by applying a 12/24V ~/

5 TECHNICAL DATA

Power supply ....................................................230 V ~ - 50Hz
Fuse F2 ............................................................5A 250V
Stabilized output ..............................................12V
Contact ...............................................double exchange, max 3A each contact
Max number of controlled transmitters ...............40
Type of managed codings .................................12 bit dip-switch / rolling code fix part only
IN1 and IN2 inputs ...........................................N.O. contact, or 12/24V ~/
INE input ...............................................N.C. contact

6 OPERATING CONDITIONS

SSE12 is designed and tested for civil electrical installations field.
WARNING Using the product under unusual conditions not foreseen by manufacturer may cause
8
dangerous situations; this is the reason why all the conditions prescribed in these instructions must be
followed.
WARNING Under no circumstance must the product be used in an explosive environment or sur-
roundings that may prove corrosive and damage parts of the product.
7

ASSEMBLY AND WIRING INSTRUCTIONS

Connect to the power supply 230 V ~ 50 Hz through a multi pole switch or a different device that can
ensure multi pole disconnection from the power supply, with a contact opening of 3,5 mm. Use a cable
with a minimum section of 3 x 1,5 mm² (H07RN-F type).
300mA output, but as the contact is released from any potential, the same
tension to proper inputs
max 300mA
