20 | English
– Switch the power tool off.
– Allow the battery to cool down before you carry on work-
ing.
If the LED indicator (6) is flashing red, then the power tool
is blocked and will switch off automatically.
Pull the power tool out of the workpiece.
The power tool will continue to work as soon as the blockage
is rectified.
Practical advice
Exercise caution when cutting slots in structural walls;
u
see the "Information on structural design" section.
When cutting lightweight materials, take into account
u
the statutory provisions and recommendations of the
material manufacturer.
Clamp the workpiece if it is not secure under its own
u
weight.
Do not load the power tool so heavily that it comes to a
u
stop.
If the power tool has been subjected to a heavy load,
u
continue to run it at no-load for several minutes to
cool down the accessory.
Do not use the power tool with a cut-off stand.
u
Do not touch grinding and cutting discs until they have
u
cooled down. The discs can become very hot while work-
ing.
If the power tool becomes electrostatically charged, the
built-in electronics will switch the power tool off. Press the
on/off switch (3) again to restart the power tool.
Rough grinding
Never use cutting discs for rough grinding.
u
The best rough grinding results are achieved with a set angle
of 30° to 40°. Move the power tool back and forth with mod-
erate pressure. This will ensure that the workpiece does not
become too hot or discolour and that grooves are not
formed.
Cutting metal
Always use the protective guard for cutting (10) when
u
cutting bonded abrasives.
When carrying out abrasive cutting, use a moderate feed
that is suited to the material being machined. Do not exert
pressure on the cutting disc and do not tilt or swing the
power tool.
Do not attempt to reduce the speed of a cutting disc coming
to a stop by applying pressure from the side.
The power tool must always work in an up-grinding motion.
Otherwise there is a risk that it will be pushed uncontrolled
out of the cut.
For best results when cutting profiles and rectangular
tubing, start at the smallest cross section.
Cutting Stone
Provide sufficient dust extraction when cutting stone.
u
Wear a dust mask.
u
1 609 92A 54P | (18.07.2019)
The power tool may be used only for dry cutting/grind-
u
ing.
For cutting stone, it is best to use a diamond cutting disc.
When cutting especially hard materials such as concrete
with a high pebble content, the diamond cutting disc can
overheat and become damaged as a result. This is clearly in-
dicated by circular sparking, rotating with the diamond cut-
ting disc.
If this happens, stop cutting and allow the diamond cutting
disc to cool down by running the power tool for a short time
at maximum speed with no load.
If work is noticeably slower and circular sparking is present,
this indicates that the diamond cutting disc has become
blunt. You can resharpen the disc by briefly cutting into ab-
rasive material (e.g. lime-sand brick).
Information on structural design
Slots in load-bearing walls are subject to DIN 1053 part 1 or
country-specific regulations. These regulations must be ob-
served under all circumstances. Seek advice from the re-
sponsible structural engineer, architect or construction su-
pervisor before starting work.
Recommendations for optimal handling of the battery
Protect the battery against moisture and water.
Only store the battery only within a temperature range of -20
to 50 °C. Do not leave the battery in your car in the summer,
for example.
Occasionally clean the ventilation slots on the battery using a
soft brush that is clean and dry.
A significantly reduced operating time after charging indic-
ates that the battery has deteriorated and must be replaced.
Follow the instructions on correct disposal.

Maintenance and Service

Maintenance and Cleaning
Remove the battery from the power tool before carry-
u
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage. There is risk of injury
from unintentionally pressing the on/off switch.
To ensure safe and efficient operation, always keep
u
the power tool and the ventilation slots clean.
Store and handle the accessories carefully.
After-Sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
Bosch Power Tools
