Product Specification
Lawnmower
Part number (typ)
Rated power
Blade width
Height of cut
Grassbox capacity
Weight (max.)
Protection class
Serial Number
Intended Use
This product is intended for domestic lawn mowing.
Introduction
This manual gives instructions on the correct as-
sembly and safe use of your machine. It is important
that you read these instructions carefully.
When fully assembled the machine weighs approxi-
mately between 11.0 and 13.5 kg. If necessary, ob-
tain assistance to remove from packaging.
Take care when carrying the mower to the lawn, as
the blades are sharp.
Delivered Items
Carefully remove the machine from its packaging
and check that you have all the following items:
– Lawnmower with handle assembly
– 1 Handle bottom
– 2 Bolts
– 2 Wing nuts
– 2 Screws
– 2 Grassbox parts (ROTAK 34/37)
– 3 Grassbox parts (ROTAK 40/43)
– 2 Cable clips
– Cable restraint (if supplied separately)
– Operating instructions
When parts are missing or damaged, please contact your
dealer.
13 • F016 L70 468 • 06.11
ROTAK 34
3 600 H81 A..
[W] 1300
[cm] 34
[mm] 20 – 70
[l] 40
[kg] 11.0
/ II
See serial No 13 (rating plate) on machine.
ROTAK 37
3 600 H81 B..
1400
37
20 – 70
40
11.2
/ II
Operating Controls
1 Switch lever
2 Safety button
3 Handle top
4 Cable restraint**
5 Mains plug**
6 Grassbox
7 Deflector guard
8 Handle bottom
9 Ventilation slots
10 Wheels
11 Grass comb
12 Height of cut lever
13 Serial Number
**Country specific
Not all of the accessories illustrated or described are
included as standard delivery.
Warning! Switch off, remove plug from mains
before adjusting, cleaning or if cable is cut,
damaged or entangled.
The blades continue to rotate for a few sec-
onds after the machine is switched off.
Caution – do not touch rotating blades.
Electrical Safety
Your machine is double insulated for safety and re-
quires no earth connection. The operating voltage is
230 V AC, 50 Hz (for non-EU countries 220 V,
240 V as applicable). Only use approved extension
cables. Contact your service agent for details.
Extension cords/leads should only be used if they
comply with H05VV-F, H05RN-F types or IEC type
design (60227 IEC 53, 60245 IEC 57).
English - 2
ROTAK 40 ROTAK 43
3 600 H81 C.. 3 600 H81 D..
1600 1700
40 43
20 – 70 20 – 70
50 50
13.2 13.5
/ II
For Your Safety
/ II
