DeWalt DCB112 Guide D'utilisation

D WALT Industrial Tool Co., 701 East Joppa Road, Towson, MD 21286
e
(FEB18) Part No. N588849
The following are trademarks for one or more D WALT power tools: the yellow and black color scheme; the "D" shaped air
e
intake grill; the array of pyramids on the handgrip; the kit box configuration; and the array of lozenge-shaped humps on the
surface of the tool.
ENGLISH
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk of
personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR ANY D
(1–800–433–9258).
WARNING!

Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
SAVE THESE INSTRUCTIONS
Important Safety Instructions for All Battery Chargers

WARNING: Read all safety warnings and all instructions for the battery pack, charger and power tool. Failure to
follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Before using the charger, read all instructions and cautionary markings on the charger, battery pack and product
•
using the battery pack.
• DO NOT attempt to charge the battery pack with any chargers other than the ones in this manual. The charger and
battery pack are specifically designed to work together.
• These chargers are not intended for any uses other than charging D
result in risk of fire, electric shock or electrocution.
• Do not expose the charger to rain or snow.
• Pull by the plug rather than the cord when disconnecting the charger. This will reduce the risk of damage to the electric
plug and cord.
• Make sure that the cord is located so that it will not be stepped on, tripped over or otherwise subjected to damage
or stress.
• Do not use an extension cord unless it is absolutely necessary. Use of improper extension cord could result in risk of fire,
electric shock or electrocution.
• When operating a charger outdoors, always provide a dry location and use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
• An extension cord must have adequate wire size (AWG or American Wire Gauge) for safety. The smaller the gauge
number of the wire, the greater the capacity of the cable, that is, 16 gauge has more capacity than 18 gauge. An undersized cord
will cause a drop in line voltage resulting in loss of power and overheating. When using more than one extension to make up the
total length, be sure each individual extension contains at least the minimum wire size. The following table shows the correct
size to use depending on cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The lower the gauge
number, the heavier the cord.
Minimum Gauge for Cord Sets
Volts
120 V
240 V
Ampere Rating
More Not
Than More
Than
0 6
6 10
10 12
12 16
DCB112 Copyright © 2018 D WALT
e
WALT TOOL, CALL US TOLL FREE AT: 1–800–4-D
e
WALT rechargeable batteries. Any other uses may
e
Total Length of Cord in Feet
(meters)
25 (7.6) 50 (15.2) 100 (30.5) 150 (45.7)
50 (15.2) 100 (30.5) 200 (61.0) 300 (91.4)
American Wire Gauge
18 16 16 14
18 16 14 12
16 16 14 12
14 12 Not Recommended
• Do not place any object on top of the charger or place the charger on a soft surface that might block the ventilation
slots and result in excessive internal heat. Place the charger in a position away from any heat source. The charger is
ventilated through slots in the top and the bottom of the housing.
• Do not operate the charger with a damaged cord or plug.
• Do not operate the charger if it has received a sharp blow, been dropped or otherwise damaged in any way. Take it to
an authorized service center.
• Do not disassemble the charger; take it to an authorized service center when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution or fire.
Disconnect the charger from the outlet before attempting any cleaning. This will reduce the risk of electric shock.
•
Removing the battery pack will not reduce this risk.
• NEVER attempt to connect 2 chargers together.
• The charger is designed to operate on standard 120V household electrical power. Do not attempt to use it on any
other voltage. This does not apply to the vehicular charger.

WARNING: Shock hazard. Do not allow any liquid to get inside the charger. Electric shock may result.

WARNING: Burn hazard. Do not submerge the battery pack in any liquid or allow any liquid to enter the battery pack. Never
attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks or cracks, return to a service
center for recycling.

CAUTION: Burn hazard. To reduce the risk of injury, charge only D
may overheat and burst resulting in personal injury and property damage.
NOTICE: Under certain conditions, with the charger plugged into the power supply, the charger can be shorted by foreign
material. Foreign materials of a conductive nature, such as, but not limited to, grinding dust, metal chips, steel wool,
aluminum foil or any buildup of metallic particles should be kept away from the charger cavities. Always unplug the charger
from the power supply when there is no battery pack in the cavity. Unplug the charger before attempting to clean.
Important Safety Instructions for All Battery Packs

WARNING: Read all safety warnings and all instructions for the battery pack, charger and power tool. Failure to
follow the warnings and instructions may result in electric shock, fire and/or serious injury.
• Do not charge or use the battery pack in explosive atmospheres, such as in the presence of flammable liquids, gases
or dust. Inserting or removing the battery pack from the charger may ignite the dust or fumes.
NEVER force the battery pack into the charger. DO NOT modify the battery pack in any way to fit into a non-
•
compatible charger as battery pack may rupture causing serious personal injury. Consult the chart at the end of this
manual for compatibility of batteries and chargers.
• Charge the battery packs only in designated D
• DO NOT splash or immerse in water or other liquids.
Do not store or use the tool and battery pack in locations where the temperature may reach or exceed 104 °F (40 °C)
•
(such as outside sheds or metal buildings in summer). For best life store battery packs in a cool, dry location.
NOTE: Do not store the battery packs in a tool with the trigger switch locked on. Never tape the trigger switch in the
ON position.
• Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when lithium ion battery packs are burned.
If battery contents come into contact with the skin, immediately wash area with mild soap and water. If battery liquid
•
gets into the eye, rinse water over the open eye for 15 minutes or until irritation ceases. If medical attention is needed, the battery
electrolyte is composed of a mixture of liquid organic carbonates and lithium salts.
Contents of opened battery cells may cause respiratory irritation. Provide fresh air. If symptoms persist, seek
•
medical attention.

WARNING: Burn hazard. Battery liquid may be flammable if exposed to spark or flame.

WARNING: Fire hazard. Never attempt to open the battery pack for any reason. If the battery pack case is cracked or
damaged, do not insert into the charger. Do not crush, drop or damage the battery pack. Do not use a battery pack or
charger that has received a sharp blow, been dropped, run over or damaged in any way (e.g., pierced with a nail, hit with a
hammer, stepped on). Damaged battery packs should be returned to the service center for recycling.
Transportation

WARNING: Fire hazard. Do not store or carry the battery pack so that metal objects can contact exposed battery
terminals. For example, do not place the battery pack in aprons, pockets, tool boxes, product kit boxes, drawers, etc., with
loose nails, screws, keys, etc. Transporting batteries can possibly cause fires if the battery terminals inadvertently
come in contact with conductive materials such as keys, coins, hand tools and the like. The US Department of
Transportation Hazardous Material Regulations (HMR) actually prohibit transporting batteries in commerce or on airplanes
in carry-on baggage UNLESS they are properly protected from short circuits. So when transporting individual battery packs,
make sure that the battery terminals are protected and well insulated from materials that could contact them and cause a
short circuit.
SHIPPING THE D WALT FLEXVOLT™ BATTERY
e
The D WALT FLEXVOLT™ battery has two modes: Use and Shipping.
e
Use Mode: When the FLEXVOLT™ battery stands alone or is in a D
will operate as a 20V Max* battery. When the FLEXVOLT™ battery is in a 60V Max* or a 120V Max*
(two 60V Max* batteries) product, it will operate as a 60V Max* battery.
Shipping Mode: When the cap is attached to the FLEXVOLT™ battery, the battery is in Shipping
Mode. Strings of cells are electrically disconnected within the pack resulting in three batteries with a lower Watt hour (Wh)
rating as compared to one battery with a higher Watt hour rating. This increased quantity of three batteries with the lower Watt
hour rating can exempt the pack from certain shipping regulations that are imposed upon the higher Watt hour batteries.
The battery label indicates two Watt hour ratings (see example). Depending on how the battery is shipped, the appropriate
Watt hour rating must be used to determine the applicable shipping requirements. If utilizing the shipping cap, the pack will be
considered 3 batteries at the Watt hour rating indicated for "Shipping". If shipping without the cap or in a tool, the pack will be
considered one battery at the Watt hour rating indicated next to "Use".
WALT
e
For example, Shipping Wh rating might indicate 3 x 40 Wh, meaning 3 batteries of 40 Watt hours each. The Use Wh rating might
indicate 120 Wh (1 battery implied).
Fuel Gauge Battery Packs (Fig. B)
Some D WALT battery packs include a fuel gauge which consists of three green LED lights that indicate the level of charge
e
remaining in the battery pack.
The fuel gauge is an indication of approximate levels of charge remaining in the battery pack according to the
following indicators:
To actuate the fuel gauge, press and hold the fuel gauge button. A combination of the three green LED lights will illuminate
designating the level of charge left. When the level of charge in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to be recharged.
NOTE: The fuel gauge is only an indication of the charge left on the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature and end-user application.
For more information regarding fuel gauge battery packs, please call 1-800-4-D
www.dewalt.com.
The RBRC® Seal
The RBRC® (Rechargeable Battery Recycling Corporation) Seal on the nickel cadmium, nickel metal hydride or
lithium-ion batteries (or battery packs) indicates that the costs to recycle these batteries (or battery packs) at
the end of their useful life have already been paid by D
cadmium, nickel metal hydride or lithium-ion batteries in the trash or municipal solid waste stream and the
Call 2 Recycle® program provides an environmentally conscious alternative.
Call 2 Recycle, Inc., in cooperation with D
and Canada to facilitate the collection of spent nickel cadmium, nickel metal hydride or lithium-ion batteries. Help protect
our environment and conserve natural resources by returning the spent nickel cadmium, nickel metal hydride or lithium-ion
batteries to an authorized D WALT service center or to your local retailer for recycling. You may also contact your local recycling
e
center for information on where to drop off the spent battery. RBRC® is a registered trademark of Call 2 Recycle, Inc.
WALT rechargeable battery packs. Other types of batteries
e
WALT chargers.
e
WALT 20V Max* product, it
e
Example of Use and Shipping Label Marking
USE: 120 Wh Shipping: 3 x 40 Wh
75–100% charged
51–74% charged
< 50% charged
Pack needs to be charged
Fig. B
WALT (1-800-433-9258) or visit our website
e
WALT. In some areas, it is illegal to place spent nickel
e
WALT and other battery users, has established the program in the United States
e
