About the device
3. Technical specifications
Mains input
Input voltage
Frequency
Fuse
Power factor
Power consumption at output off
Output 1&2 - Voltage
Adjustable range
Stability at mains fluctuation
±10% ∆U
IN
Stability at 0...100% load
Ripple BWL 20MHz
Accuracy*
Overvoltage protection
Regulation time 10-90% load
Softstart
Output 1 & 2 - Current
Adjustable range
Stability at mains fluctuation
±10% ∆U
IN
Stability at 0...100% ∆U
OUT
Ripple
Accuracy*
Output 1 & 2 - Power
Efficiency
Nominal power P
nom
Output 3
Adjustable range
Power
Stability at mains fluctuation
±10% ∆U
IN
Stability at 0...100% load
Ripple
Nominal current
Miscellaneous
Operation temperature
Storage temperature
Humidity rel.
Dimensions (WxHxD)
Weight
Cooling
Safety
EMC standards
Overvoltage class
Protection class
Article number
* Related to the nominal value, the accuracy defines the maximum allowed deviation between set value and actual value.
Example: a 42V model has min. 0.2% voltage accuracy, this is 84mV. When setting a voltage of 5V and with an allowed maximum deviation of 84mV,
the resulting actual value could be between 4.92V and 5.08V.
16 Date: 11-13-2019
PS 2342-06B PS 2342-10B
100...240V ±10% 100...240V ±10%
45...65 Hz
MT 4 A
> 0.99
24W
0...42 V
< 0.02%
< 0.15%
< 100mV / < 4mV < 63mV
PP RMS
≤ 0.2%
0...46.2 V
< 2 ms
max. 200 ms
0...6 A
< 0.05%
< 0.15%
< 25mA / < 4mA < 13mA
PP RMS
≤ 0.3%
≤ 85%
2x 100W
3...6 V
10 W (max. 12 W) 10 W (max. 12 W)
< 0.02%
< 1.2%
< 100 mVpp
>2 A @ 5 V
>3.3 A @ 3 V
0....50°C
-20....70°C
< 80%
282x82x241 mm 282x82x241 mm
3,3 kg
39200120
PS 2384-03B
100...240V ±10%
45...65 Hz 45...65 Hz
MT 6,3 A MT 4 A
> 0.99 > 0.99
24W
0...42 V 0...84 V
< 0.02% < 0.02%
< 0.15% < 0.15%
/ < 5mV < 48mV
PP RMS PP
≤ 0.2% ≤ 0.2%
0...46.2 V 0...92.4 V
< 2 ms < 2 ms
max. 200 ms max. 200 ms
0...10 A 0...3 A
< 0.05% < 0.05%
< 0.15% < 0.15%
/ < 5mA < 6mA
PP RMS PP
≤ 0.3% ≤ 0.3%
≤ 85% ≤ 85%
2x 160W 2x 100W
3...6 V 3...6 V
10 W (max. 12 W)
< 0.02% < 0.02%
< 1.2% < 1.2%
< 100 mVpp < 100 mVpp
>2 A @ 5 V >2 A @ 5 V
>3.3 A @ 3 V >3.3 A @ 3 V
0....50°C 0....50°C
-20....70°C -20....70°C
< 80% < 80%
282x82x241 mm
3,5 kg 3,3 kg
fanless, natural convection
EN 60950
EN 61326, EN 55022 Class B
Class II
Class I
39200121 39200125
PS 2384-05B
100...240V ±10%
45...65 Hz
MT 6,3 A
> 0.99
24W 24W
0...84 V
< 0.02%
< 0.15%
/ < 4mV < 96mV / < 24mV
RMS PP
≤ 0.2%
0...92.4 V
< 2 ms
max. 200 ms
0...5 A
< 0.05%
< 0.15%
/ < 2mA < 9mA / < 3mA
RMS PP
≤ 0.3%
≤ 85%
2x 160W
3...6 V
10 W (max. 12 W)
< 0.02%
< 1.2%
< 100 mVpp
>2 A @ 5 V
>3.3 A @ 3 V
0....50°C
-20....70°C
< 80%
282x82x241 mm
3,5 kg
39200126
