User's guide
Eagletone MULTI DERBY
5. HOW TO CONTROL THE FIXTURE
There are two ways to control the fixture:
A. Universal DMX controller
The fixture can be remotely controlled by
a universal DMX controller, once its DMX
address has been set. First, you need to
program two scenes into a chase, and
then link the fixtures to the universal DMX
controller. When you run the chase, all the
fixtures in the chain will have their DMX
address set automatically. The fixture
uses four channels. Please refer to the
following diagram to set the address for
the first four units.
6
B. Master/Slave operation
The fixture will allow you to link 16 fixtures
together to operate without a controller.
In Master/Slave mode, the first fixture will
control the others to give an automatic,
sound-activated, synchronized light show.
This function is ideal when you want to
provide an instant show. Do not connect
any cable to the first fixture's DMX input
XLR connector, and the other fixtures will
be set to slave mode automatically. Link
the other fixtures by connecting the DMX
output connector to the next fixture's DMX
output XLR connector (daisy chain), and
so on, until all the fixtures are linked. Any
fixture can act as a Master or as a Slave.
6. DMX512 CONFIGURATION
Custom control by DMX512 (CH1=0)
Channel
Value
Function
CH1
0
Custom control
CH2
0
Moon flower turned off
1-255
Moon flower running speed from slow to fast
CH3
0
High-power LED turned off
1-202
7 colors selection
203-231
7 colors jump change
232-255
Gradual change
CH4
0-255
Strobe speed from slow to fast. (CH4=0, strobe
off) (CH3: 1-202)
Running speed in jump change mode (CH3:
203-231)
Running speed in gradual change mode (CH3:
232-255)
CH5
0
Motor stop
1-255
Motor rotation from slow to fast
CH6
0
None
1-255
Strobe speed from slow to fast
Calling auto show or sound mode (CH1>0)
Channel
Value
Function
CH1
1-33
Auto show 1
34-67
Auto show 2
68-101
Auto show 3
102-135
Auto show 4
136-169
Auto show 5
170-203
Auto show 6
204-237
Auto show 7
238-255
Sound mode
CH2
0-255
Running speed in auto show mode
CH3
0-255
Motor speed in auto show mode
User's guide
Eagletone MULTI DERBY
7
