User's guide
Eagletone MULTI DERBY
4. HOW TO SET UP THE UNIT
4.1 Display and buttons
MENU
Allows to select the programming
functions
UP
Allows to increase parameter values
DOWN
Allows to reduce parameter values
ENTER
Allows to enter submenu
DMX Signal indicator light
Whenever a DMX signal is detected,
this indicator light flashes.
Slave Signal indicator light
Whenever a Slave signal is detected,
this indicator light flashes.
4
Note
If no button is pressed for ten seconds,
the LED display turns off. Press any
button to turn the LED display back on.
Whenever a button is pressed, the
program will save all parameters after
2 seconds.
DMX or SLAVE signals are detected
automatically, independently of the
mode or program in which the unit may
be, so the program will jump into DMX
or SLAVE mode automatically. If the
DMX or SLAVE signal happens to be
disconnected, the program will return
to the original mode.
4.2 Main function chart
M EN U
User's guide
Eagletone MULTI DERBY
DMX address/Slave mode
Auto show mode
Running speed
Motor speed
Sound mode
Software version
5
