NATURAL GAS CONVERSION INSTRUCTION
12
(bellows connect to
Connect
Natural Gas Hose
Quick Disconnect
Bellows
Locate the new NG valve, verify it is the correct one, the lable
with
NATURAL GAS VALVE
Re-attach bellows to the NG Valve.
For ONE piece Bellows models, please see E.
For TWO pieces Bellows models, please see D&E.
Re-attach thermocouple to NG Valve.(see F)
Please note that the valve has an air inlet and an air outlet with arrows
indicating the flow direction of the
Natural Gas Piping
Orifice Spud
Failure to follow the instructions could result in fire or explosion,
which could cause property damage, personal injury, or death.
Gas inlet
NG source)
D
Connect
Gas inlet
Valve
should be on the new NG valve.
!
IMPORTANT
Quick Disconnect and NG Hose
Burner.
NATURAL GAS VALVE
VANNE A GAZ NATUREL
F
Gas outlet
9 / 40
gas,the gas comes out of from the
E
Gas outlet
(bellows connect to
burner)
Bellows
!
WARNING
When connecting the bellows, please ONLY
turn the brass joint counterclockwise on the
bellows.Do not rotate the stainless steel tube.
Excessive rotation of the stainless steel tube
will cause the gas pipe to twist or break,
causing gas leaks.
SS tube
Brass joint
Valve
Connect
Burner
Brass joint
