Controls
OSM
(On-Screen Manager) control buttons on the front of the monitor function
™
as follows:
Main Menu
Exits the OSM menu.
EXIT
NOTE:
Moves the highlighted
CONTROL
area left/right to select
one of the sub-menu.
NOTE: When the OSM menu is off, CONTROL acts as a Hot key for Brightness.
CONTROL
Has no function
-/+
NOTE:
SELECT/
While in OSM, this will enter the
SBMODE
sub-menu. If OSM is off, this button
will turn on the SuperBright function.
NOTE: When the OSM is off, it will act as the SuperBright (SB) function key.
User can select between SB MODE OFF, SB MODE1, and SB MODE2. The first
time this key is pressed, the current SB Mode is indicated. Within a 3 second
window, if this key is selected again, the SB MODE will change to the next SB
MODE. For example, the current mode is SB MODE OFF, the key is pressed
twice within a 3 second time frame, the SB MODE will change to SB MODE1
and so on. The color temperature at each SB Mode is adjusted by appropriate
color control except for the sRGB mode whose color setting cannot be adjusted.
When the unit is turned off, it will reset to SB off mode.
Resets all the controls within the
RESET
highlighted menu to the factory
setting.
NOTE: When RESET is pressed in the main and sub-menu, a warning window
will appear allowing you to select the reset function.
Brightness/Contrast Controls
Brightness: Adjusts the overall image and background screen brightness.
Contrast: Adjusts the image brightness in relation to the background.
Degauss: Eliminates the buildup of stray magnetic fields which alter the correct scan of the
electron beams and affect the purity of the screen colors, focus and convergence. When
activated, your screen image will jump and waver a bit as the screen is demagnetized.
NOTE: Please allow a minimum of 20 minutes to elapse between uses of the Degauss Control.
Size and Position Controls
Left/Right: Moves the image horizontally (left or right).
Down/Up: Moves the image vertically (up or down).
Narrow/Wide: Decreases or increases the horizontal size of the image.
Short/Tall: Decreases or increases the vertical size of the image.
MSFP912SBManual.p65
Deactivates the OSD menu and activates the OSD menu when the OSD is turned off.
CONTROL button will act as a "Hot Key" for Contrast when the OSM is off and Hot Key is on.
5
5
Sub-Menu
Exits to the OSM controls
main menu.
Moves the highlighted area
left/right to select one of the
controls.
Moves the bar in the – or +
direction to decrease or
increase the adjustment.
Has no function
Resets the highlighted control to
the factory setting.
8/5/02, 2:09 PM
