Technical data
CAN-L - 1
V
bat+
CAN-H - 4
Nominal
Minimum
Maximum
Current consumtion in operational mode
Power consumption
Oil consumption
Supply
voltage
Without
voltage
With voltage
Oil viscosity
Oil
viscosity
Note: Max. start up viscosity 2500 mm
Filtering
Filtering in
the hydraulic
system
2
PVED-CC
Pin no.
1
- 2
2
3
4
Function
Pilot oil
flow per
neutral
PVED-CC
locked
Pilot oil flow
one actuation
(neutral → max.)
per PVED-CC
continuous
actuations
range 12 - 75 mm
2
/s [65 - 347 SUS]
4 mm
2
/s [39 SUS]
min.
460 mm
2
/s [2128 SUS]
max.
2
/s
Max. allowed degree of
contamination (ISO 4406,
1999 version): 18/16/13
11085226 • Rev BB • Mar 2014
1 - CAN-L
U
2 - V
DC
bat+
CAN-L
CAN-H
4 - CAN-H
157-574.13
Supply voltage
Power consumption
PVED-CCD-CC
Code no. 157B4943
[0.106 US gal/min]
[0.053 US gal/min]
[0.053 US gal]
[0.290 US gal/min]
Oil temperature
Oil
-temperature
PVED-CC
CAN-L
U
DC
2
3
2
3
CAN-H
1
4
1
4
157-741.13
11 - 32 V
11 V
32 V
750 mA
9 W
4 l/min
0.2 l/min
0.002 l
1.1 l/min
range 30 - 60˚C [86 -140˚F]
-30˚C [-22˚F]
min.
90˚C [194˚F]
max.
