ENG USER MANUAL
Thank you for choosing the products of Armytek.
Please read this manual carefully before using the flashlight.
Specifications
1. Headlamp: simple one-hand operation, reliable headmount. Solid
body without long wires, weak rubber connectors and unnecessary
boxes. The flashlight is easily installed, removed and 180° rotatable in
the mount. Quick-release silicone ring provides additional fixation
2. Every Day Carry light: compact design, convenient side button,
special matt anti-abrasive finish without rough knurling. Robust
removable steel clip and strong built-in tail magnet
3. Sports flashlight: body made from durable and lightweight
aircraft-grade aluminium, improved shock resistance, constant light
without flickering. Multiple variants of installation, optional accessories
for mounting on sporting gear
4. Lamp mode: works without batteries directly from a Powerbank or
any USB power supply
• Possibility to set the timer for automatic switching-off
Model
Optics
Brightness stabilization type
Light output
Peak beam intensity
Hotspot : Spill
Beam distance
Modes, light output and runtimes (measured
with 18650 Li-Ion 3200 mAh battery until the
light output drops to 10% of the initial value)
Power source
Time of charging (18650 Li-Ion 3200 mAh battery)
Length/Body diameter/Head diameter
Weight without/with battery
Ingress protection, Submersion and Impact resistance
X All the above specifications are test results based on ANSI/PLATO FL 1-2019 Standard. The data may vary due to environment, heat dissipation and other factors.
2 ENG USER MANUAL ELF C2
Elf C2 (white light)
TIR
DIGITAL (CPU brightness control)
1100 lm
2770 cd
70°:120°
105 m
Turbo
1100 lm/2 h 32 min (650 lm after 4 min)
Main3
500 lm/3 h 45 min
Main2
220 lm/10 h
Main1
43 lm/38 h
Firefly2 2 lm/26 d
Firefly1 0.11 lm/200 d
1x18650 Li-Ion
4 h 30 min
111.3 mm/20.4 mm/33 mm
65 g/115 g
IP68. Depth up to 10 m for 5 h. Height up to 10 m
• Multicolor temperature, battery level, charging process and state
indication
• Convenient wide beam of fully upgraded optical system, steel bezel
and tempered glass with anti-reflective coating for protection of the
TIR-lens
• Innovative technology allows using any standard 18650 Li-Ion
battery even without additional protection circuit board
• Active real-time temperature control to prevent overheating above
+58 °C
• Total protection from water, dirt and dust in accordance with
IP68 standard — flashlight continues to work even after submersion
at 10 meters depth. Withstands fallings from up to 10 meters
• Robust and water resistant USB-C socket even without rubber cover
Elf C2 (warm light)
1023 lm
2690 cd
104 m
1023 lm/2 h 32 min (605 lm after 4 min)
465 lm/3 h 45 min
205 lm/10 h
40 lm/38 h
1.9 lm/26 d
0.1 lm/200 d
