Operating Instructions
UC-3ACX004
65 W USB GaN Charger
Item no: 2745929
1 Intended use
The product is a USB-C® and USB-A GaN (gallium nitride) charger with support for PD
(power delivery) fast charging. It supports 4 different plug types, see section
[} 4].
The product is intended for indoor use only. Do not use it outdoors.
Contact with moisture must be avoided under all circumstances.
If you use the product for purposes other than those described, the product may be dam-
aged.
Improper use can result in short circuits, fires, electric shocks or other hazards.
The product complies with the statutory national and European requirements.
For safety and approval purposes, you must not rebuild and/or modify the product.
Read the operating instructions carefully and store them in a safe place. Make this product
available to third parties only together with the operating instructions.
All company names and product names are trademarks of their respective owners. All rights
reserved.
USB4®, USB Type-C® and USB-C® are registered trademarks of USB Implementers
Forum.
2 Delivery contents
■
Product
■
3x Interchangeable plugs
■
Operating instructions
3 Latest product information
Download the latest product information at
code shown. Follow the instructions on the website.
4 Description of symbols
The symbol warns of hazards that
can lead to personal injury.
This product must only be used in
dry, enclosed indoor areas. It must
not become damp or wet, as this
may cause a fatal electric shock!
5 Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling, we assume no liability for any resulting personal injury or
damage to property. Such cases will invalidate the warranty/guarantee.
5.1 General
■
The product is not a toy. Keep it out of the reach of children and pets.
■
Do not leave packaging material lying around carelessly. This may become dangerous
playing material for children.
■
If you have questions which remain unanswered by this information product, contact our
technical support service or other technical personnel.
■
Maintenance, modifications and repairs must only be completed by a technician or an
authorised repair centre.
5.2 Handling
■
Handle the product carefully. Jolts, impacts or a fall even from a low height can damage
the product.
5.3 Operating environment
■
Do not place the product under any mechanical stress.
■
Protect the appliance from extreme temperatures, strong jolts, flammable gases, steam
and solvents.
■
Protect the product from high humidity and moisture.
■
Protect the product from direct sunlight.
■
Do not switch the product on after it has been taken from a cold to a warm environment.
The condensation that forms might destroy the product. Allow the product to reach room
temperature before you use it.
3
Technical data
www.conrad.com/downloads
or scan the QR
The symbol warns of dangerous
voltage that can lead to personal in-
jury by electric shock.
Protection class 2 (double or rein-
forced insulation, protective insula-
tion).
5.4 Operation
■
Consult an expert when in doubt about the operation, safety or connection of the
product.
■
If it is no longer possible to operate the product safely, take it out of operation and pro-
tect it from any accidental use. DO NOT attempt to repair the product yourself. Safe op-
eration can no longer be guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
– has been stored for extended periods in poor ambient conditions or
– has been subjected to any serious transport-related stresses.
5.5 Electrical safety
Do not modify or repair mains supply components including mains plugs, mains
cables, and power supplies. Do not use damaged components. Risk of death by
electric shock!
■
Connect the product to a mains socket that can be accessed easily.
■
Only connect the product to a mains socket connected to the public supply. Before con-
necting, check whether the voltage stated on the rating plate complies with the voltage of
your electricity supplier.
■
Never connect or disconnect the product if your hands are wet. There is a risk of electric
shock.
■
For safety reasons, disconnect the product from the mains socket during storms.
■
Do not touch the product if there are any signs of damage, as this may cause a fatal
electric shock! Take the following steps:
– Switch off the mains supply to the product (switch off the corresponding circuit breaker
or remove the safety fuse, and then switch off the corresponding RCD protective
switch).
– Remove the product from the mains socket.
– Do not use the product again. Prevent others from using it.
5.6 Connected devices
■
Also observe the safety and operating instructions of any other devices which are con-
nected to the product.
6 Interchangeable plugs
■
There are three interchangeable plugs in addition to the integrated plug.
■
Fold the integrated plug into the housing before attaching an interchangeable plug. The
attachment should "click" into place.
■
Slide the unlock switch on the bottom of the plug to release an attachment.
7 Charging combinations
The maximum charging output depends on which combination of ports are used.
These diagrams show different port combinations and maximum outputs.
7.1 1x port
7.2 2x ports
7.3 3x ports
8 Cleaning
Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They damage the housing and can cause the product to malfunction.
– Do not immerse the product in water.
1. Disconnect the product from the power supply.
2. Let the product cool down to ambient temperature.
3. Clean the product with a dry, fibre-free cloth.
