SOMFY Amy 1 RS100 io Notice page 6

EN
To add or delete Amy 1 RS100 io, use the Somfy local io control point already paired
with the motorised product.
1] Position the motorised product at its half-way position.
2] On the individual control point already paired with the motorised product:
ð Press the PROG button until the motorised product moves up and down:
programming mode is activated.
3] On Amy 1 RS100 io to be added or deleted:
ð Briefly press the PROG button: the motorised product moves up and
down and Amy 1 RS100 io is added or deleted.
2.3.Switching on Amy 1 RS100 io
For transportation, Amy 1 RS100 io is switched off: the front panel buttons (Up, Stop/my, Down) are deactivated.
To check whether Amy 1 RS100 io is switched on or off, press any front panel button and see if the feedback LED lights up.
1] To activate the front panel buttons, long press the On/Off button until the
settings feedback LED lights up green. It switches from Off status to On
status.
2] To deactivate the front panel buttons, long press the On/Off button until the
settings feedback LED lights up red: this indicates the Off status.
NOTICE
The PROG button and the mode selector are always active, even when the front panel buttons are deactivated by the
On/Off button.
2.4.Optimization of temperature sensor performance
To ensure optimum performance of the embedded temperature sensor, follow these
recommendations:
▪ Prefer wall mounting to reach higher performance of the sensor (accuracy and
repeatability). Temperature measurement will thus be more consistent with
temperature felt in the room.
▪ Avoid placing Amy 1 RS100 io in direct sunlight.
▪ Place it away from any source of heat or cold (ideally 1 m from a radiator, an
air conditioner, a wood stove,...).
▪ Place it away from direct airflow (at least 25 cm from an opening).
▪ Avoid enclosed area, where the sensor will not be influenced by the
surrounding air.
2.5.Wall mounting
NOTICE
• The use of radio appliances operating on the same frequency may cause interference and reduce the product's
performance.
• Never use the control point near a metal frame or metal surfaces, as this can reduce the radio range.
• The environment in which the product is used might reduce the radio range.
• The use in the same floor as the controlled products is recommended.
• Radio range in free field: 150 m.
There are two possible ways of wall-mounting Amy 1 RS100 io, depending on the type of back cover:
6
1]
2]
3]
1]
2]
©
Copyright 2024 SOMFY ACTIVITES SA. All rights reserved.
Amy 1 RS100 io
2 s
0.5 s
>2 s
>2 s
