ASSE M BLY / ASSEMBLAGE / ASAMBLEA
PA RTS LI ST
Key
Qty
Description
1
1
TOP LID
2
1
THERMOMETER
3
1
LOGO PLATE F/ LID
4
1
HANDLE F/ LID
5
1
TOP LID HARDWARE
6
2
LID STOP
7
3
RUBBER BUMPER, W/ HOLE
8
1
FIREBOX
9
1
LEFT, FIREBOX PANEL
10
1
RIGHT, FIREBOX PANEL
11
3
BURNER BRACE
12
3
MAIN BURNER
13
3
ELECTRODE, F/ MAIN BURNER
14
2
CARRY OVER TUBE
15
1
UPPER CONTROL PANEL
16
1
CONTROL PANEL, MAIN
17
1
IGNITER SWITCH MODULE
18
3
BEZEL F/ CONTROL KNOB
19
3
CONTROL KNOB
20
1
HOSE VALVE REGULATOR ASSEMBLY
21
1
HEAT SHIELD, F/ CONTROL PANEL
22
1
LEFT SIDE SHELF
23
2
UPPER FASCIA, F/ SHELF
24
1
MAIN FASCIA, F/ LEFT SIDE SHELF
25
1
LOWER FASCIA, F/ LEFT SIDE SHELF
26
1
END CAP, F/ LEFT SHELF
27
1
RIGHT SIDE SHELF
28
1
MAIN FASCIA, F/ RIGHT SIDE SHELF
29
1
LOWER FASCIA, F/ RIGHT SIDE SHELF
30
1
END CAP, F/ RIGHT SHELF
31
1
BRACE F/ EI MODULE
32
1
ELECTRONIC IGNITION MODULE
33
1
CAP, F/ IGNITION MODULE
34
1
SHIELD, F/ ELECTRONIC IGNITION MODULE
35
1
UPPER REAR PANEL
36
1
LEFT, CART FRAME
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from those on your particular grill model. However, the
method of assembly remains the same.
Key
Qty
Description
37
1
RIGHT, CART FRAME
38
1
HEAT SHIELD, F/ TANK
39
1
DOOR, NO HANDLE
40
1
FIXED PIN, F/ DOOR
41
1
SPRING PIN, F/ DOOR
42
1
DOOR HANDLE
43
1
DOOR CORNER FASCIA
44
1
GRIDDLE STORAGE BRACKET
45
1
LOWER REAR PANEL
46
1
BOTTOM SHELF
47
1
TANK SCREW, F/ BOTTOM SHELF
48
2
MAGNET BRACE
49
2
MAGNET ASSEMBLY
50
2
CASTER, LOCKING
51
2
WHEEL
52
1
AXLE, F/ WHEEL
53
1
WHEEL CAP
54
2
TANK EXCLUSION
55
1
MATCH HOLDER
56
2
RAIL, F/ GREASE TRAY
57
1
GREASE TRAY
58
2
EMITTER, F/ COOKING GRATE, 120
59
2
COOKING GRATE, 120
60
1
EMITTER, F/ COOKING GRATE, 180
61
1
COOKING GRATE, 180
62
1
WARMING RACK
63
1
GRIDDLE
64
1
HOSE/ REGULATOR REPLACEMENT ONLY
65
1
WIRE CLIP
NOT Pictured
...
1
PRODUCT GUIDE
...
1
HARDWARE PACK
...
1
CLEANING TOOL
...
1
CASTER PIN
P a g e 3 9
C H A R B R O I L . C O M
