GB MT
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
The device is part of the X 12 V TEAM
series and can be operated with bat-
teries of the X 12 V TEAM series. Bat-
teries of the X 12 V TEAM series may
only be charged using chargers of the
X 12 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Cordless Impact Wrench
• 4×Socket: 17/19/21/23 mm
• Storage case
• Translation of the original instructions
The rechargeable battery and
charger are not included in deliv-
ery.
Overview
The illustrations for the
device can be found on the
front fold-out page.
1 Tool holder
2 Display (level)
3 Speed button
4 Charge level indicator on the device
5 Handle (Insulated gripping surface)
6 Battery release
7 Battery
20
8 On/Off switch
9 Direction of rotation switch
10 LED work light
11 Socket
12 Storage case
13 Charger
Description of functions
The cordless impact wrench has clock-
wise/anticlockwise rotation and a ½"
external square drive. The rotary impact
function of the tool converts the force of
the motor into uniform rotary impacts. The
striking mechanism switches on when tight-
ening and loosening materials.
Please refer to the descriptions below for
information on how the operating ele-
ments work.
Technical data
Cordless Impact Wrench
...............................PPDSSA 12 A1
Rated voltage U ............................. 12 V ⎓
Weight with battery (12 V, 4 Ah) .≈1.3 kg
No-load rotation speed n
........................................ 1200-2700 min
–Level 1 ................................0-1200 min
–Level 2 ................................0-1700 min
–Level 3 ................................0-2100 min
–Level 4 ................................0-2700 min
Impact rate
–Level 1 ................................0-1100 min
–Level 2 ................................0-2100 min
–Level 3 ................................0-2600 min
–Level 4 ................................0-3200 min
Torque
–Level 1 ...........................................85 Nm
–Level 2 ........................................ 125 Nm
–Level 3 ........................................ 200 Nm
–Level 4 ........................................ 300 Nm
0
−1
−1
−1
−1
−1
−1
−1
−1
−1
