Ramiaudio DEM113 Manuel Utilisateur page 12

FRONT PANEL
1
2 - How to change the reference level value
AES Input : Lock
Fs : 192.0KHz
L
R
Note :
- A short press on the "Select" button changes the
value step by step.
- A long press on the "Select" button changes the
value quickly (values scroll).
3 - Selection key.
4 - "Enter" key to access the display menu.
5 - Power indicator light.
Rami
AES Input : Lock Stereo
Fs : 192.0KHz
L
R
2
Stereo
SELECT
ENTER / MENU
3 4
one press on
"Enter/Menu"
1 press on
12
DEM 113
ON
Digital MPX Stereo Demodulator
MPX Status
MPX Level :
Pilot Level :
Ref. Level :
one press on
"Select"
MPX Status
MPX Level :
Pilot Level :
Ref. Level :
one press on
"Enter/Menu"
MPX Status
MPX Level :
Pilot Level :
Ref. Level :
"Select"
modify the value
Next
5
56.0KHz
7.2KHz
-3.0dB
74.4KHz
7.4KHz
-3.0dB
74.3KHz
7.3KHz
-3.0dB
DEM113
