MECHANICAL FEATURES
The IA504D digital amplifier has been designed with particular attention to optimising its weight and overall
size. With dedicated accessories, it can be installed in a half-rack unit or in a standard rack. It weighs 1.82 kg.
The dimensions are: 222 mm (L) x 44 mm (H) x 256,5 mm (D).
AMPLIFIER AND CONTROL SECTION FEATURES
The IA504D new generation class D digital amplifier offers a total amplification power of 500 W RMS. The AD/DA
conversion stage is 48 kHz - 24 bit. The connections offer application flexibility, and include:
- four balanced analogue audio inputs on 3.81mm Euroblock connectors (Input 1 and 2 could be set as AES/
EBU Input and Output)
- four power outputs in 5.08mm Euroblock format
- two Ethernet ports capable of supporting the transmission of four Dante® digital inputs and outputs
- USB port
- four configurable GPIO (General Purpose Input/Output) ports
- standby input
!
CAUTION
• Protect the unit from humidity.
• Do not attempt to open the amplifier.
• In the event of malfunction, immediately turn off the power, disconnect the unit from the mains
and contact an authorised service centre.
