Fig. 12. Bottom view.
Fig. 13. Rear view.
The connection terminals are located at the bottom of the unit,
as shown in the following table:
Item Terminal

DC switch

DC input terminal

COM1 port

COM2/COM3 port

AC output terminal
Tab. 4. Connection terminals.
USER MANUAL
 

Rear
rail
Rear
rail
Note
On/Off switch
PV Connector
WiFi/LAN/GPRS/4G connector
CT/RS485/DRED connector
Connection for AC output




Rear
rail
Rear
rail
EQX2 SOLAR INVERTERS CONNECTED TO THE GRID
