Radio Timing Repeater; Introduction - Gorgy Timing RADIO TIMING NETWORK Mode D'emploi

2.1. INTRODUCTION

TYPICAL INSTALLATION :
Waterproof Antenna
GPS, DCF or France Inter.
MDE-RTnetwork-3076V1.2
2.

RADIO TIMING REPEATER

The terminal recovers radio information resulting
from a principal transmitter and repeats it by hert-
zian way to the slave clocks.
The radio transmission allows an easy installation
of the product by removing the wire connection
between the transmitter and the clocks while pre-
serving a high degree of accuracy.
LEDI 7•S
®
RTCP
TGV clock
Access Control
LEDICA ALPHA 7 • 60 • M • S
®
09
®
RTCP09
Ligthning
OK
20.59 46
Air conditioning
GORGY TIMING
BACK
Heating
pool
12 dry contacts outputs
