1.2. QUICK START

This part contains the useful information about the radio timing installation Radio.

1.2.1. Fixings and installation

The product can be put on a wall at a minimum distance from the floor of 1 meter.
☛
Metallic room and wall must be avoid in order to keep the best

1.2.2. Functioning WITH TDF/DCF ANTENNA

► Use the switch on the side face of the product for setting the address of the trans-
mitter. If you use many transmitters please select a different address for each one:
Switch N°0
OFF
OFF
OFF
OFF
ON
ON
ON
ON
► The transmitter must be plug on a 230VAC power supply source. TDF or DCF an-
tenna must be plugged and correctly installed. For a cold start (first start) the red led
on the front face is Flashing in time with radio code.
► If a correct TDF or DCF code is received the red led is Flashing at one-second inter-
vals. It means radio transmission is occurring. The transmission last for 4 minutes.
Then the red led is lighted until the next correct TDF or DCF data reception.
MDE-RTnetwork-3076V1.2
1. RADIO TIMING NETWORK TDF/DCF GPS AFNOR
☛
Some rules must be respected.
performances of the system.
Switch N°1 Switch N°2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
ADRESS
0
1
2
3
4
5
6
7
