AM1 adjustment module
The AM1 adjustment module shown below is designed for use on PH10M-iQ PLUS providing roll, pitch and yaw adjustment. It has a quick
release mechanism allowing rapid head exchange and features inbuilt overtravel protection. For further information on the AM1, please refer
to the AM1 user's guide (Renishaw part number H-1000-4010).
