! If the appliance is connected to liquid gas, the
adjustment screw must be fastened as tightly as
possible.
5. Turn the knob from the MAX position to the MIN
position quickly or open and shut the oven door,
making sure that the burner is not extinguished.
Adapting the grill
Replacing the grill burner
nozzle:
1. Remove the oven burner
V
after loosening screw V (see
fi gure).
2. Unscrew the grill burner
nozzle using a special nozzle
socket spanner (see fi gure) or
I
preferably with a 7 mm socket
spanner, and replace it with a new nozzle that is
suited to the new type of gas (see Burner and nozzle
specifi cations table).
! Be careful of the spark plug wires and the
thermocouple tubes.
! The oven and grill burners do not require primary air
adjustment.
! After adjusting the appliance so it may be used with
a different type of gas, replace the old rating label with
a new one that corresponds to the new type of gas
(these labels are available from Authorised Technical
Assistance Centres).
Table of burner and nozzle specifications
Table 1
Burner
Diameter
(mm)
Fast
100
(Large)(R)
Semi Fast
75
(Medium)(S)
Auxiliary
51
(Small)(A)
Oven
-
Grill
-
Nominal (mbar)
Supply
Minimum (mbar)
Pressures
Maximum (mbar)
Thermal power
By-Pass
kW (p.c.s.*)
1/100
Nominal
Reduced
(mm)
3,00
0,7
41
1,90
0,4
30
1,00
0,4
30
2.80
1.0
46
2,30
-
-
! Should the gas pressure used be different (or vary
slightly) from the recommended pressure, a suitable
pressure regulator must be fitted to the inlet hose in
accordance with current national regulations relating to
"regulators for channelled gas".
TECHNICAL DATA
Oven dimensions
(HxWxD)
Volume
Useful
measurements
relating to the oven
compartment
Power supply voltage
and frequency
Burners
Gaz liquide
Gaz naturel
Nozzle
Flow*
Nozzle
1/100
g/h
1/100
(mm)
***
**
(mm)
87
218
214
128
70
138
136
104
52
73
71
76
80
204
200
119
75
167
164
114
28-30
37
20
25
35
45
34x38x44 cm
57 l
width 42 cm
depth 44 cm
height 17 cm
see data plate
may be adapted for use with any
type of gas shown on the data
plate, which is located inside the
flap or, after the oven
compartment has been opened,
on the left-hand wall inside the
oven.
EC Directives: 2006/95/EC dated
12/12/06 (Low Voltage) and
subsequent amendments -
2004/108/EC dated 15/12/04
(Electromagnetic Compatibility)
and subsequent amendments -
90/396/EEC dated 29/06/90 (Gas)
and subsequent amendments -
93/68/EEC dated 22/07/93 and
subsequent amendments -
2002/96/EC.
1275/2008 (Stand-by/ Off mode)
WARNING! The glass lid can break
in if it is heated up. Turn off all the
burners and the electric plates before
closing the lid. *Applies to the models
with glass cover only.
S S
A
R
Flow*
l/h
KN3G2/EX
KN3G210/EX
KN1G21/EX
286
181
95
S
267
A
R
219
20
17
25
KN3M21/EX
GB
Ø180
7
