Exploded Drawing; Parts List - Homcom A91-182 Manuel D'instructions
Table des Matières
Les langues disponibles
Les langues disponibles
NO
NAME
1
Main Frame
2
Rear stabilizer
3
Anti-slip plate
4
Adjustable subassembly
5
Front stabilizer
6
Poam subassembly
7
Poam
8
Knob(M16)
9
Screw M8*16
EXPLODED DRAWING
PARTS LIST
QTY
NO
1
10
1
11
1
12
1
13
1
14
2
15
6
16
1
17
2
EN-3
NAME
Screw M8X70
Washer M8
Nut M8
Washer M6
Screw M6*20
Bench Subassembly
Pin
Standing
QTY
4
4
4
4
2
1
1
1
