LIGHTING THE GAS PILOT
1. Turn the main gas shut-off valve
and
the
individual
valves OFF. Wait 5 minutes.
2. Turn the main gas shut-off valve
ON.
3. Light each pilot using an outside
ignition source. Pass the ignition
source through the pilot access
hole in the front panel and ignite
the pilot (Fig. 12). The end of the
ignition source will need to be at
least 7" long so it can extend pass
the front panel to reach the pilot
inside.
4. While viewing through the pilot
access
hole,
corresponding
pilot
until
the pilot has a slight yellow
tip
5. Repeat steps 3-4 until all pilots
are lit.
6. To light the burners, turn the
individual burners valves ON (MAX
setting) after all pilots are lit. (Fig.
13). If the burners fail to light, turn
all burner valves and the main gas
shut-off valve to the OFF position
and contact an authorized service
agency.
CLEANING
The
and its parts are hot.
when
operating,
servicing the charbroiler.
Scrape top grates during broiling
with a wire brush to keep the
grates clean.
Do not allow debris
to accumulate on the grates. (Fig.
14)
burner
gas
Fig. 10
adjust
the
valve
screw
charbroiler
Use care
cleaning
or
Pilot
Pilot Valve
10
-
-
Pilot Access Hole
Fig. 12
Fig. 13
Fig. 14
