getemed PhysioMem PM 100 2G Instructions D'utilisation page 28

Recording and sending an ECG
C – ECG in storage –
D – ECG in storage –
E – ECG sent –
After sending, the main display is shown again.
Each ECG recording successfully sent is then deleted from the
storage.
The mobile transmission module is switched off automatically.
If the transmission of one or several ECG fails immediately after
recording, the transmission process is repeated automatically.
PhysioMem repeats the transmission at the following time intervals:
first repetition immediately after failure of the first transmission

process
three further repetitions each after 15 minutes

next repetition after 5 hours and after every 24 hours

NOTE
If the ECG data cannot be transmitted, e.g., because of a poor mobile
network connection, changing the location of the device is
recommended (e.g., go outdoors, change the side of the street, etc.).
Observe the times set by the repetition intervals described above. If
the mobile network connectivity is always insufficient in your area,
send the ECG from another area.
NOTE
The transmission process cannot be repeated manually.
28
connection to mobile network established
connection to ReSTA established
connection to ReSTA / status message
