Fig. 6
3. Install the fl ue pipe into the fl ue outlet.
Assembly of fl ue pipe with rear outlet
If the fl ue pipe is to be rear mounted do the following:
NB! In order to make the change, you must fi rst remove
the baffl e plate - see fi g. 23 - 24. Remember to put it in
place later.
Fig. 7
1. Unscrew the screw (A) and remove the rear heat shield.
Fig. 8
2. Mount the fl ue outlet (A) into the rear outlet.
Fig. 9
A
• Fasten the cover on the top plate.
ENGLISH
A
9
