APBC1001
Data Link Cable Diagram
OUTPUTS
Pumps
Solenoids
Motors
HVAC
Lighting
0–10V/0–11.5V Signal
ZONE A
Analog Input
ZONE A
Digital Output
IMPORTANT:
cables and high voltage AC power harness as far as possible from each other for stable signal
transmission. Avoid coiling data as well as AC harnesses in tight coils. Excess cable should be
managed by creating long loops as opposed to tight coils.
APBC1001 – USER MANUAL
Controller
Light Sensors
I/O
Module
PH/EC Sensors
T/RH Sensors
Enviro Sensors
Outputting
ZONE B
Analog Input
Digital Output
Do not attach data link cables to power cable. Always keep low voltage data
PART 1
System
Data PC
INPUTS
CO Sensors
512 Fixtures Total
ZONE A
ZONE A
256 Fixtures
ZONE B
6 6
2
OF
PHANTOM 50
APBC1001 =
ZONE B
ZONE B
256 Fixtures
