note:
When burning, a good indicator that logs are installed correctly is that each flame stands reasonably straight. If a
log splits a flame or drastically changes the direction of a flame, review instructions again and/or pivot log out of
direct contact.
IF APPLICABLE, USE THIS BOX TO SHOW
"NATURAL GAS ONLY" LOG PLACEMENT.
Natural Gas Models Only:
PLACE TEXT BOX HERE.
