General
To comply with the Canadian Electrical Code and the Canadian
Standards Association, the load center must be installed in
accordance with the information included on the label on the
inside of the equipment. This must also be done in accordance
with the applicable local electrical codes and by a qualified
electrical contractor or licensed electrician.
WARNING: Hazard of electrical shock or burn. Turn off
power supplying this equipment before working inside.
Installation
1 – Remove the Door
Back out the door hinges. Remove the door and slip it back
into the carton to protect the finish. Save the screws for reuse.
2 – Remove the Shield
a. Loosen the fastening screw (the screw will be retained in
the shield).
b. Insert a screwdriver under the loop, then lift the shield
up and out.
c. Slip the shield back into the carton to protect the finish.
3 - Remove the Service Entrance Barrier (Main
Breaker only)
Back out and save the mounting screw securing the service
entrance barrier over the main breaker connections, then lift
the barrier up and out.
DEH40229
Installation Instructions
PowerMark Plus™ Load Centers
100–225 Ampere Single- and Three-Phase 10–42
Circuit
Rainproof
Barrier
Mounting
Screw
4 – Remove the Interior (Optional)
Back out the mounting screws and save them for reuse.
Mounting
Screws
5 – For Top Feed, Screw the Hub (Not Included)
onto the Installed Conduit
Raintight hubs can be installed in any of the four positions
indicated below.
