11 Technical Data
Operating conditions
Mechanical construction
User interface
Power supply
Certificates and approvals
Ordering
Standards, guidelines
40
All manuals and user guides at all-guides.com
Installation
Mounting In any orientation. Mounting only in housings F6, F10 or T3
(with raised cover) of Multicap T or Multicap probes.
Environmental conditions
Ambient temperature range -40 °C...+70 °C
Limiting temperature range -40 °C...+80 °C
Storage temperature range -40 °C...+85 °C
Climatic class Climatic protection to IEC 68, Part 2...38, Fig. 2a
Ingress protection IP 20
Vibration resistance To IEC 68 Part 2-6, 10...55 Hz, 0.15 mm, x,y,z
Electromagnetic compatibility Interference Emission to EN 61326; Electrical Equipment Class B
Interference Immunity to EN 61326; Annex A (Industrial) and
NAMUR Recommendation NE 21 (EMC).
Housing
Design Compact instrument
Dimensions 103 mm x 67 mm x 49 mm
Weight 0.3 kg
Material Plastic
Electrical connection See Section 3, Page 28-29
Outside the protective cover
Green LED Stand-by
Red LED Switching status:
AC version (relays de-energised)
DC version (switching output blocked)
Under the protective cover
5 LEDs Display of gradations with values
2 keys Calibration / assigning values
Rotary switch For selecting 8 different settings (see Page 31)
AC version AC 90 ...253 V, 50/60 Hz, current consumption approx. 10 mA at 230 V
DC version Three-wire DC connection PNP, DC 10 V...55 V
Certificates EC-Type-examination certificate
KEMA 99 ATEX 3122, XA 060F/00/a3
CE Mark By attaching the CE Mark, Endress+Hauser confirms that the
electronic insert FEC 22 fulfils all legal requirements of the relevant EC
directives.
Order No.: 942299-0000 FEC 22 in AC version
Order No.: 942299-1000 FEC 22 in DC version
Supplementary Multicap T DC .. TE. probe, TI 240F/00/en
Documentation Multicap T DC .. TA. probe, TI 239F/00/en
Multicap DC .. E. probe, TI 242F/00/en
Multicap DC .. A. probe, TI 243F/00/en
Elektronic insert FEC 22
