4
Module status LED
LED status Description
Off No voltage supply
Green Normal operation
Red Serious error, module status is "EXCEPTION"
Flashing red Error, the current IP settings are not the same as those in net.cfg.ob.
An LED test is run after start-up.
Connection/activity LED
LED status Description
Off No connection, no activity
Green Connection established
Green, flickering Activity on the interface
An LED test is run after start-up.
1.2 The Anybus module web interface
With the web interface, you can read out and modify all the process variables
and the indicator network settings. Enter the IP address of the Anybus module
into any web browser you choose.
If you do not know the address, use the "Anybus IPconfig" program to find it. If
necessary, you can download the program from http://www.anybus.de.
You can also modify the following Modbus parameters:
• Modbus Connection Timeout
• Modbus Process Timeout
• Modbus Word Order
1.3 Configuring the Anybus module
For configuration, we recommend using the Modbus Poll program from
Modbus Tools (http://www.modbustools.com), also see
http://www.modbus.org.
