OPERATION MANUAL
Dear Customer!
This manual contains important information and
advice for the correct and safe use and
maintenance of the ZIPPER mitre saw. The
manual is part of the machine and may not be
stored separately. Read it profoundly before
first use of the machine and keep it for later
reference. When the machine is handed to other
persons always put the manual to the machine.
Please follow the security instructions!
Due to continuous development of our products
illustrations, pictures might differ slightly.
Attention!
Technical changes reserved!
Copyright
© 2010
This manual is protected by copyright law
rights reserved. Especially the reprinting as well
as the translation and depiction of pictures will
be prosecuted by law. Court of jurisdiction is
WELS, Austria.

Customer Support

Z.I.P.P.E.R MASCHINEN GmbH
Gewerbepark 8
A-4707 Schlüßlberg
Tel 0043 (0) 7248 61116 - 700
Fax 0043 (0) 7248 61116
info@zipper-maschinen.at
all
720
1 TECHNICS
1.1

Technical Details

Voltage
Engine power (S1/S6)
Engine speed
Protection class
Maximum teeth on saw
blade
Saw blade diameter
Diameter of the saw
blade bore
Maximum thickness of
the saw blade
Maximum cutting
powers:
Cutting power 0°/ 90°:
Cutting power 45°/ 90°:
Cutting power 0° / 45°:
Cutting power 45° / 45°:
Laser details
Wave length of the laser
Laser power
Packing size
weight (net/gross):
Noise emission: weighted
Lp
Noise emission: weighted
Lw
1.2 Components (Fig. A)
1. Saw blade
safety lock
2. Operation
handle
3. ON/OFF switch
4. Saw aggregate
5. Saw blade
6. Saw blade
safety cover
7. Work piece
EN
230V/50 Hz
1.6/2,0 kW
5000 rpm
II
40
250 mm
30 mm
2.8 mm
305 x 78 mm
215 x 78 mm
305 x 42 mm
205 x 42 mm
Class II, EN
60825
650 nm
< 1 mW
760 x 460 x 385
mm
17 / 20 kg
86.0 dB(A)
99.0 dB(A)
Against unintentional
lowering of the saw
aggregate
With 1. and 3.
Turns on the engine, saw
blade in rotation
Pivotable
HM-saw blade; take care of
the maximum dimensions!
Do not remove!
Adjustable
