Description
No.
1
2
3
4
5
6
7
8
9
*
Special adapter + flex coupling necessary with electric motor IEC 132 L, Nema C type 184 T and 215 T.
Order numbers can be found under section Code numbers.
** Directional valve without coil - please order seperatly
Code numbers
Item
PPH 10
PPH 12.5
Mounting kit for electric motor
Mounting kit for electric motor
incl. SAE fittings
*Coil for bypass valve, please order separately
Coil
24 V / 50 Hz
220 V / 50 Hz
240 V / 50 Hz
24 V / 60 Hz
110 V / 60/50 Hz
12 V d.c.
24 V d.c.
220 V / 50 Hz EEX
Item
Description
Flexible coupling
For motor type IEC 100 L / 112 L / 132 L - B5 flange*
Nessie PAH pump
Type PAH 10 or PAH 12.5
For motor IEC 100 L /112 L / 132 L and pump flange
Bell housing
ISO 3019/2 - 80 A2 HW
VPH 15 E (15 l/min)
Power-pack-valve - 2/2-way directional valve incl. pressure relief valve**
Filter
Return filter incl. pressure switch and air breather (3 µm)
Monitor device
Temperatur and level monitoring
Volume 60 l (net volume between min. and max. level: 11 l),
Tank
material: plastic
Hose (transparent)
Tank drain, visual tank level monitoring
Ball valve
Filling device
For electric motor type
NEMA C 184 T and 215 T
Code numbers
018Z7905
018Z7906
018Z7909
018Z7907
018Z7908
018Z7915
018Z7916
018Z7992
Code numbers*
IEC 100/IEC 112
180B0292
IEC 100/IEC 112
180B0291
IEC 132
180B0293
180B0294
P : G 3/8
-
Pressure outlet
T : G 3/8
-
Tank line
M : G 3/8
-
(plugged) pressure gauge
W: G 1/4
-
Water inlet
3
