Cubix™ 2.0 QRG
Menu Options
Main Level
DMX Address
Auto Programs
Auto Program
Speed
Sound Active
Mode
DMX Linking
Starting Address
Master/Slave
Connection
DMX Values
6-CH
Channel Function
Programming Levels
512
AUTO
S--
SNd
The Cubix™ 2.0 can work with a DMX controller when linked by DMX
serial connections. Instructions for connecting and configuring this product
for DMX operation are in the User Manual. If you are not familiar with
DMX, download the DMX Primer from www.chauvetlighting.com.
To ensure full access to all channels in each DMX mode, the highest
recommended DMX address is 507.
The Cubix™ 2.0 uses the DMX data connection for its Master/Slave mode.
Instructions for connecting and configuring this product for Master/Slave
operation are in the User Manual.
1 Colors
2 Strobe
3 Motor Rotation
4 Auto Programs
Auto Program
5
Speed
6 Strobe
d__1-d512 Sets the DMX starting address
Sets Auto Program
S__1-S100 Selects Auto Program speed (slow to fast)
Sets Sound-Active mode
Value Percent/Setting
000  004
No function
005  028
Red
029  056
Green
057  084
Blue
085  112
Cyan
113  140
Purple
141  168
Yellow
169  197
White
198  224
3 Colors Switching
225  255
7 Colors Switching
000  004 No function
005  255 0-30 Hz
Rotate clockwise (slow
000  127
to fast)
128  255 back and forth
000  014 Blackout
015  255 Auto Programs
000  015 No function
0-100% (when Ch. 4 is
016  255
between 015-255)
000  015 No function
016  255 0-30 Hz
4
Description
Side Lens
Middle Lens
EN
