Checking the Installation
Check the following items:
EN
1.
Status of the main control board LEDs and of the other control elements connected.
Consult the Self-diagnostics section on each element's technical fact sheet.
2.
The main control board LEDs indicating the opening of motorized elements light up in
sequence.
3. Power supply to wired and wireless thermostats.
CAN
N
8
AZ1 AZ2
ON/OFF Module
D6 D7
AZxxxCBxMOT v1.0
AI1 DI1
O1 O2
L
AZ3 SW1
D4 D5
D3
M1 M2 M3 M4 M5 M6 M7
Blinking
Steady
Switches
D2
D1
D8
D9
M1...M8 M1...M8
(Green) Damper
opening
(Red) Damper
closing
M8
