• It is recommended to place the car seat in the centre rear seat if equipped with a
three-point safety belt.
• If the car seat is positioned on the front seat, for greater safety, it is recommended to
move the vehicle seat back as far as possible, if feasible with the presence of other
passengers in the rear seat and to adjust the backrest to the most upright position.
• If the car is equipped with a seat belt height adjuster, fix this at the lowest position.
• Ensure that the seat belt adjuster is in the rear position (or most aligned) with the
vehicle seat backrest.
• It is not recommended to install the car seat on the front seat if equipped with an
active front AIRBAG.
• In the case of installation on any seat protected by an airbag, always refer to the car
instruction manual.

CAR SEAT ASSEMBLY

Raise the backrest to the vertical position, a clack will indicate correct attachment.
Before use, check that the backrest is locked in the vertical position, it must not fold
down when pushed forward.

1. ADJUSTING THE HEADREST

A correctly adjusted headrest ensures that the diagonal seat belt section is optimally
positioned, and gives your child the optimal protection.
The headrest must be adjusted so that there is a space two fingers wide between the
headrest and your child's shoulders.
To adjuste the height of the headrest to fit your child:
1. Reach into the adjustment handle on the back of the headrest and pull it upwards.
This unlocks the headrest (1A-1B).
2. You can now move the unlocked headrest to the desired height. As soon as you
release the adjustment handle, the headrest will lock into place (1C).
3. Place the child seat on the vehicle seat. Have your child sit down in the child seat and
check the height. Repeat this process until the headrest is at the optimal height (1D).
2. INSTALLATION WITH 3-POINT SAFETY BELT IN COMBINATION WITH ISOFIX
CONNECTORS
Please read the instructions on the use of child restraint systems described in your
vehicle owner's manual. Find the ISOFIX anchorage points in the vehicle seat.
Tips: the ISOFIX anchorage points are located between the surface and the backrest
of the vehicle seat.
Insert two Smart Fix guides to the ISOFIX lower anchorages respectively (2A) ISOFIX
guides make it easier to install using the Smart Fix connectors and prevent damage to
the upholstery.
1. Remove the vehicle seat headrest if it prevents you from adjusting the car seat
headrest to the desired height (2B, 2C).
